Automatic Stretch Hooding Machine
STRETCH HOODING MACHINE
The Stretch Hooding Machine is a fully automated packaging system designed to secure and protect palletized loads using highly elastic tubular stretch film. The film is stretched and pulled over the complete load to provide stable and reliable packaging.
The system creates a five-sided protective barrier around the pallet, helping protect packaged goods from dust, moisture and external handling conditions. Automatic film feeding, cutting, sealing and hood application provide consistent packaging performance for industrial production and logistics operations.
Technical Features
| Model | Variable Ratio Stretch Hooding Machine | Fixed Ratio Stretch Hooding Machine | |
|---|---|---|---|
| Capacity | Transport speed 250 mm/s, product size 750L×750W mm, 25% stretch | ||
| Output (ind. pallet H:1800 mm) | < 80 pal/h | < 100 pal/h | |
| Output (ind. pallet H:1200 mm) | < 90 pal/h | < 110 pal/h | |
| Output (ind. pallet H:1000 mm) | < 100 pal/h | < 120 pal/h | |
| Output (ind. pallet H:600 mm) | < 110 pal/h | < 130 pal/h | |
| Compressed air pressure | 0.5-0.7 MPa | 0.5-0.7 MPa | |
| Air consumption | 140 L/min, ANR | 300 L/min, ANR | |
| Max. product heights | 1800 mm | 1800 mm | |
| Min. cross-sectional dimensions of packaging | 600 x 600 mm | 600 x 600 mm | |
| Max. cross-sectional dimensions of packaging | 1350 x 1350 mm | 1400 x 1400 mm | |
| Min. transport height | 600 mm | 600 mm | |
Characteristics
Reliable Protection. Greater Efficiency. Lower Packaging Costs.
Engineered with advanced materials and technology, our stretch hooding system ensures superior load protection, secure wrapping and cost-efficient packaging for a wide range of products.
High-strength
protection
Made from high-quality raw materials and advanced processes, it enhances tensile and tear resistance, effectively resisting external impacts and ensuring the safety of products.
→
Efficient
protection
High transparency and excellent self-adhesion, dustproof, moisture-proof, UV-resistant, with added rust protection, suitable for various products.
→Cost-saving
High tensile strength and large elongation rate, reducing material usage while maintaining excellent wrapping effect, significantly lowering packaging costs.
→
