2 in 1 – 4 Head Fully Automatic Agarbatti & Dhoop Stick Counting & Packing Machine
2 in 1 – 4 Head Fully Automatic Agarbatti & Dhoop Stick Counting & Packing Machine
The 2 in 1 – 4 Head Fully Automatic Agarbatti & Dhoop Stick Counting & Packing Machine is designed for automated counting and packaging of both agarbatti and dhoop sticks. The machine combines two counting systems in one solution, with 2 heads dedicated to dhoop sticks and 2 heads for incense sticks, helping manufacturers handle different stick products efficiently.
Designed for continuous packaging operations, the machine provides accurate counting, consistent pouch quantities and automated packing performance. Its PLC-based control system with a 7-inch HMI supports convenient operation, while automatic and manual operating modes provide flexibility for different production requirements.
Technical Specifications
| Machine Speed | 5 to 30 Pouch / Minute (Depends on Size & Quantity) |
|---|---|
| Production Capacity | 2400 to 15000 Pouch / 8 Hours |
| Required Power | 6 HP Single Phase (3 HP Compressor) |
| Dhoop Stick Length | 3" to 10" |
| Incense Stick Length | 8" to 12" |
| Dhoop Stick Diameter | 2.8 to 10 mm (As per Customer Requirement) |
| Incense Stick Diameter | 2.8 to 3.5 mm (As per Customer Requirement) |
| Packaging Roll | 80 mm to 250 mm BOPP Heat Sealable (22 to 50 Micron) |
| Sealing Type | Center Sealing or Side Sealing as per Requirement |
| Counting System | 2 Head Dhoop Stick Counting + 2 Head Incense Stick Counting |
| Control System | PLC Based Programming with 7" HMI |
| Operating System | Automatic & Manual Operation |
| Temperature Display | Temperature Indication for Cutting and Sealing Temperature |
| Machine Structure | Heavy Rigid Structure |
| Machine Operation | Easy Operating System |
| Automatic Stop | Machine Auto Stop While Material is Finished |
| Suite | 1 Suite Installed and 2 Suite Free with Machine as per Requirement |
